電機類型：永磁同步電機（PMSM）
供電電壓：24V/48V/72V/96V/110V/310V/560V
功率范圍：50W-20KW
編碼器類型：增量/絕對值/旋轉變壓器
產品參數
1. 伺服電機型號定義
TY 130 SV - 150 30 - B A - Z48
型號 ：
① ② ③ ④ ⑤ ⑥ ⑦
①-基座號 40/60/65/80/90/110/130/180/220 ②-系列 SV：伺服電機，EX：防爆伺服電機
③-額定功率 ③*10W，比如150代表150*10=1500W ④-額定轉速 ④*100 RPM，比如30代表30*100=3000RPM
⑤-額定電壓 A:24VDC B:48VDC C:72VDC D:310VDC(220VAC) E:560VDC(380VAC) F:96VDC G:110VDC H:60VDC
⑥-編碼器 A:增量磁編 B:多摩川協議多圈絕對值 C:Postial多圈絕對值 D:Hengstler機械多圈絕對值 E:增量光編 F:旋轉變壓器
⑦-抱閘電壓 無：24VDC 48:48VDC 60:60VDC 72:72VDC 96:96VDC
2. 伺服電機標準型號
TYSV系列伺服電機標準型號 | |||||||
品名 | 機座號 | 額定功率 | 額定轉速 (RPM) | 額定扭矩 (NM) | 驅動器輸入電壓(VDC) | 抱閘 | 型號 |
伺服電機 | 40 | 100W | 3000 | 0.32 | 24/48/60/72/96/110/310/560 |
| TY40SV-01030⑤⑥ |
伺服電機 | 100W | 3000 | 0.32 | 24/48/60/72/96/110/310/560 | R | TY40SV-01030⑤⑥-Z⑦ | |
伺服電機 | 60 | 100W | 3000 | 0.32 | 24/48/60/72/96/110/310/560 |
| TY60SV-01030⑤⑥ |
伺服電機 | 100W | 3000 | 0.32 | 24/48/60/72/96/110/310/560 | R | TY60SV-01030⑤⑥-Z⑦ | |
伺服電機 | 200W | 3000 | 0.64 | 24/48/60/72/96/110/310/560 |
| TY60SV-02030⑤⑥ | |
伺服電機 | 200W | 3000 | 0.64 | 24/48/60/72/96/110/310/560 | R | TY60SV-02030⑤⑥-Z⑦ | |
伺服電機 | 400W | 3000 | 1.28 | 24/48/60/72/96/110/310/560 |
| TY60SV-04030⑤⑥ | |
伺服電機 | 400W | 3000 | 1.28 | 24/48/60/72/96/110/310/560 | R | TY60SV-04030⑤⑥-Z⑦ | |
伺服電機 | 600W | 3000 | 1.9 | 24/48/60/72/96/110/310/560 |
| TY60SV-06030⑤⑥ | |
伺服電機 | 600W | 3000 | 1.9 | 24/48/60/72/96/110/310/560 | R | TY60SV-06030⑤⑥-Z⑦ | |
伺服電機 | 80 | 400W | 3000 | 1.28 | 24/48/60/72/96/110/310/560 |
| TY80SV-04030⑤⑥ |
伺服電機 | 400W | 3000 | 1.28 | 24/48/60/72/96/110/310/560 | R | TY80SV-04030⑤⑥-Z⑦ | |
伺服電機 | 750W | 3000 | 2.38 | 24/48/60/72/96/110/310/560 |
| TY80SV-07530⑤⑥ | |
伺服電機 | 750W | 3000 | 2.38 | 24/48/60/72/96/110/310/560 | R | TY80SV-07530⑤⑥-Z⑦ | |
伺服電機 | 1000W | 3000 | 3.2 | 24/48/60/72/96/110/310/560 |
| TY80SV-10030⑤⑥ | |
伺服電機 | 1000W | 3000 | 3.2 | 24/48/60/72/96/110/310/560 | R | TY80SV-10030⑤⑥-Z⑦ | |
伺服電機 | 110 | 1000W | 3000 | 3.2 | 24/48/60/72/96/110/310/560 |
| TY110SV-10030⑤⑥ |
伺服電機 | 1000W | 3000 | 3.2 | 24/48/60/72/96/110/310/560 | R | TY110SV-10030⑤⑥-Z⑦ | |
伺服電機 | 1500W | 3000 | 4.77 | 24/48/60/72/96/110/310/560 |
| TY110SV-15030⑤⑥ | |
伺服電機 | 1500W | 3000 | 4.77 | 24/48/60/72/96/110/310/560 | R | TY110SV-15030⑤⑥-Z⑦ | |
伺服電機 | 130 | 1.5KW | 3000 | 4.77 | 24/48/60/72/96/110/310/560 |
| TY130SV-15030⑤⑥ |
伺服電機 | 1.5KW | 3000 | 4.77 | 24/48/60/72/96/110/310/560 | R | TY130SV-15030⑤⑥-Z⑦ | |
伺服電機 | 1.5KW | 2500 | 6 | 24/48/60/72/96/110/310/560 |
| TY130SV-15030⑤⑥ | |
伺服電機 | 1.5KW | 2500 | 6 | 24/48/60/72/96/110/310/560 | R | TY130SV-15030⑤⑥-Z⑦ | |
伺服電機 | 2.0KW | 3000 | 9.5 | 48/60/72/96/110/310/560 |
| TY130SV-20020⑤⑥ | |
伺服電機 | 2.0KW | 3000 | 9.5 | 48/60/72/96/110/310/560 | R | TY130SV-20020⑤⑥-Z⑦ | |
伺服電機 | 3KW | 3000 | 9.5 | 48/60/72/96/110/310/560 |
| TY130SV-30030⑤⑥ | |
伺服電機 | 3KW | 3000 | 9.5 | 48/60/72/96/110/310/560 | R | TY130SV-30030⑤⑥-Z⑦ | |
伺服電機 | 3KW | 2000 | 14.3 | 48/60/72/96/110/310/560 |
| TY130SV-30020⑤⑥ | |
伺服電機 | 3KW | 2000 | 14.3 | 48/60/72/96/110/310/560 | R | TY130SV-30020⑤⑥-Z⑦ | |
伺服電機 | 3.2KW | 1500 | 19.5 | 48/60/72/96/110/310/560 |
| TY130SV-32015⑤⑥ | |
伺服電機 | 3.2KW | 1500 | 19.5 | 48/60/72/96/110/310/560 | R | TY130SV-32015⑤⑥-Z⑦ | |
伺服電機 | 180 | 4KW | 2000 | 19.5 | 48/60/72/96/110/310/560 |
| TY180SV-40020⑤⑥ |
伺服電機 | 4KW | 2000 | 19.5 | 48/60/72/96/110/310/560 | R | TY180SV-40020⑤⑥-Z⑦ | |
伺服電機 | 4.2KW | 1500 | 27 | 48/60/72/96/110/310/560 |
| TY180SV-42015⑤⑥ | |
伺服電機 | 4.2KW | 1500 | 27 | 48/60/72/96/110/310/560 | R | TY180SV-42015⑤⑥-Z⑦ | |
伺服電機 | 5KW | 2500 | 19.5 | 48/60/72/96/110/310/560 |
| TY180SV-50025⑤⑥ | |
伺服電機 | 5KW | 2500 | 19.5 | 48/60/72/96/110/310/560 | R | TY180SV-50025⑤⑥-Z⑦ | |
伺服電機 | 5.5KW | 1500 | 35 | 48/60/72/96/110/310/560 |
| TY180SV-55015⑤⑥ | |
伺服電機 | 5.5KW | 1500 | 35 | 48/60/72/96/110/310/560 | R | TY180SV-55015⑤⑥-Z⑦ | |
伺服電機 | 5.7KW | 2000 | 27 | 48/60/72/96/110/310/560 |
| TY180SV-57020⑤⑥ | |
伺服電機 | 5.7KW | 2000 | 27 | 48/60/72/96/110/310/560 | R | TY180SV-57020⑤⑥-Z⑦ | |
伺服電機 | 7.5KW | 1500 | 48 | 48/60/72/96/110/310/560 |
| TY180SV-75015⑤⑥ | |
伺服電機 | 7.5KW | 1500 | 48 | 48/60/72/96/110/310/560 | R | TY180SV-75015⑤⑥-Z⑦ | |
伺服電機 | 10KW | 2000 | 48 | 48/60/72/96/110/310/560 |
| TY180SV-100020⑤⑥ | |
伺服電機 | 10KW | 2000 | 48 | 48/60/72/96/110/310/560 | R | TY180SV-100020⑤⑥-Z⑦ | |
伺服電機 | 10KW | 1500 | 64 | 48/60/72/96/110/310/560 |
| TY180SV-100015⑤⑥ | |
伺服電機 | 10KW | 1500 | 64 | 48/60/72/96/110/310/560 | R | TY180SV-100015⑤⑥-Z⑦ | |
伺服電機 | 220 | 10KW | 1000 | 98 | 72/96/110/310/560 |
| TY220SV-100010⑤⑥ |
伺服電機 | 10KW | 1000 | 98 | 96/110/310/560 | R | TY220SV-100010⑤⑥-Z⑦ | |
伺服電機 | 15KW | 1500 | 98 | 96/110/310/560 |
| TY220SV-150015⑤⑥ | |
伺服電機 | 15kW | 1500 | 98 | 96/110/310/560 | R | TY220SV-150015⑤⑥-Z⑦ | |
伺服電機 | 20KW | 2000 | 98 | 96/110/310/560 |
| TY220SV-250020⑤⑥-Z⑦ | |
伺服電機 | 20KW | 2000 | 98 | 96/110/310/560 | R | TY220SV-250020⑤⑥-Z⑦ | |
